Semikron SKD 115/16 Bridge
Semikron SKD 115/16 Bridge

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

SEMIKRON

SKD 115/16

SKU: 825763
In stock
Usually ships within 24 -48 hours
Request a Quote
Ready to work out of the box!

All tools are delivered with essential accessories and easy-to-follow instructions. Unbox and start your projects with confidence!

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Video chat Chat Email +55 555-12345

SKD 115/16 - Semikron Danfoss Power Module

  • Current (A): 110 A
  • Dimensions (LxWxH): 81x46x17
  • Features: Compact design SKiiP technology: thermal pressure contact, no base plate and no hard mould Two screws mounting Heat transfer and isolation through direct copper board (low R th ) Low resistance in steady-state and high reliability High surge currents Up to 1800 V UL recognized, file no. E 63 532
  • Housing: SEMIPONT 5
  • Surge current (A): 1150 A
  • Technology: Bridge
  • Topology: Rectifier
  • Typical applications: Three phase rectifiers for power supplies Input rectifiers for variable Rectifiers for DC motor field supplies Battery charger rectifiers
  • Voltage (V): 1600 V
